Rockwell Automation GMLC Reference Manual User Manual
Page 160
Publication GMLC-5.2 - November 1999
Chapter
4
Using the Imaginary Axis
The imaginary axis (available only in firmware 2.2 and later) is an
internal axis with no connection to a drive or encoder. It is used as a
master axis that other real axes are synchronized to when no physical or
virtual axis is available. As such, it can be thought of as a built-in virtual
axis not requiring AxisLink. As shown below, the output of the imaginary
axis is its command position—it has no actual position.
