Publication GMLC-5.2 - November1999
593
In the Tag Explorer, select both Axis System Variables and the desired
physical axis, then select Axis_it_limit_status in the Tag Window.
System Module Fault Status 1394
System_Module_Fault_Status_1394 is an integer value representing the
highest priority fault condition currently active in the system module. The
table below shows the System Module Fault 1394 Status 1394 values, and
the corresponding message that appears in a System Fault 1394 field in
the runtime display (if enabled).
In the Tag Explorer select General System Variables, then select
System_module_fault_status_1394 in the Tag Window.
Fault Value Description Runtime Display
10 System_smrt_pwr_pre-charge_ fault _
1394 CUR FLT
9 System_smrt_pwr_i_limit_fault_1394 CUR FLT
8 System_smrt_pwr_shunt_timeout_
fault_1394 STF FLT
7 Ring Fault RNG FLT
6 Control Power Loss CTR FLT
5 Buss Over Voltage Fault BOV GLT
4 Buss Loss Fault BUS FLT
3 Phase Loss Fault PHS FLT
2 Over Temperature Fault TMP FLT
1 Ground Fault GND FLT
0 No Faults SYST OK
