800 1394 GMC Turbo SLC Interface
4. Complete SLC M File Configuration portion of the dialog box, by
making the following entries:
Field Description
Enable
Transfers Select this checkbox to enable transfers.
Transfer Mode Select a transfer mode.
Refer to the Transfer mode section for more
information.
M0 Floats Type the number of floats you need in the M0
file.
M0 Integers Type the number of integers you need in the
M0 file.
M1 Floats Type the number of floats you need in the M1
file.
M1 Integers Type the number of integers you need in the
M1 file.
