Rockwell Automation GMLC Reference Manual User Manual
Page 883
Publication GMLC-5.2 - November 1999
846
Going Online
4. Make entries in the following fields in the Variable Range to Upload
area:
5. Make entries in the following fields in the Cam Table Range to
Upload area:
6. Select Upload.
Cam Points
Upload the cam points of the
script only.
Program
Upload the executable portion
of the program only.
All
Upload the script.
Field
Description
Lower Variable
Address
Type the address of the lowest variable that
you want to upload.
Upper Variable
Address
Type the address of the highest variable that
you want to upload.
Field
Description
Lower Variable
Number
Type the address of the lowest Cam table
variable that you want to upload.
Upper Variable
Number
Type the address of the highest Cam table
variable that you want to upload.
