Data Bits Table 871
Data Bits Table
The following table lists the Data Bits alphabetically by their descriptive
name as displayed in the scroll-down display of the Control Settings
window. The Data Bit number follows the description. The Disabled and
Enabled columns show the value set when either 0 or 1 is selected. The
final column shows the Default values that are set when the i
CODE .I
command (Initialize Control) is executed to initialize the software. Data
bits marked with an asterisk (*), are not axis specific.
Data Bits
Description Bit # Disabled (0) Enabled (1) Default
Auto Program Boot* B29 No Yes 0
AxisLink* B48 No Yes 0
AxisLink Extended Node
Enabled B60 No Yes 0
AxisLink Virtual Axis B51 Disable Enable 0
AxisLink Virtual Axis
Commanded B50 Actual Command 0
Backlash Takeup Direction B13 Negative Positive 0
Common Bus
AC/DC Mode 1394 B64 No Yes 0
Common Bus Enable 1394 B63 No Yes 0
CNET Enabled 1394 B65 No Yes 0
DH-485/CNET Auto Update
Enabled B59 No Yes 0
DH-485 Enabled* B53 No Yes 0
Drive Fault Checking B17 No Yes 0
