Control Settings 191
Whenever you power-up the motion controller—or whenever you press
the Reset button, the working values are initialized (i.e., set equal to the
power-up values). At this moment, immediately after power-up, the
power-up and working values of each data parameter or data bit are
identical. Each time you run the application program in the motion
controller, the motion controller again initializes the working values (i.e.
sets them equal to the power-up values). However, the program itself may
modify the working values, thereby making the working values, of each
data parameter or data bit, different from the power-up values. In
addition, you can change the working values either directly using an
Adjust Type Control Setting block, or indirectly through the action of
other blocks.
Tag Explorer
Select either Data Bits or Data Parameters.
Tag Window
Select the Data Bit or Data Parameter that you want to read, show or
adjust.
Data Parameters
When you select Data Parameter, the available data parameters appear in
a scroll-down list. A list of these data parameters appear in the Data
Parameter table located in Appendix A of this manual.
Data Bits
When you select Data Bits in the lower-left window, the available data
bits appear in a scroll-down list in the lower-right window. These data bits
are displayed in the Data Bits table located in Appendix A of this manual.
!
ATTENTION: Do not enter values that do not fit the
selected Value Format. Unpredictable operation may occur.
