Configuring Your SLC Interface 51
Note: CNET I/O files have 32 words of I/O available. Each float
consists of two 16 bit words. I/O floating point addressing starts
at the word following the last discrete I/O. If you select 8 or 24
discrete I/O points, you can define up to 15 floats. If you
configure all 40 I/O points, you can define up to 14 floats.
Configuring Your SLC Interface
To configure the SLC interface:
1. In the Configure Control Options dialog box, select SLC.
2. Select the SLC tab. The SLC page appears.
Output Bits Select the number of input bits you need from the
pull down list. Available values are:
• 8 (0-7)
• 24 (0-23)
• 40 (0-39)
Output Floats Select the number of input floats you need from
the pull down list. The available values are 0 to 15
(or 14 see note below table).
Field Description
