Publication GMLC-5.2 - November 1999
Configure Auto Display 427
When a given axis status is displayed, any status condition of lower
priority can also be active. For instance, if axis status is shown as HRD
LIM, a SFT LIM condition may also be active and feedback may be
OFF .
When the highest priority fault is cleared, the next highest priority active
status value appears in the field.
When entering an input format, use the # character as a place holder to
denote significant digits. Use a decimal point (.) to display decimal
information. To display the value as a positive or negative signed
quantity, place a + character at the beginning of the numeric format.
Without the + character, only the magnitude of the value is displayed. For
example, a format of ### displays integers between 0 and 999, while a
format of +### displays integer values between –999 and +999.
The number of characters displayed in a numeric value field is always
equal to the total number of characters in the format data entry box
regardless of the value. Leading spaces and trailing zeros are
automatically added to fill out the defined format.
If the absolute value of the variable or expression is too large to be
displayed using the specified format, it is displayed as a field of Xs. For
example, if a format of +###.### is used to display a variable or
expression with a current value 1000.3, the resulting display is
+XXX.XXX .
HOMING Homing
MOVING Moving or Executing Time-Lock Cam
JOGGING Jogging
UNLOCK Axis Unlocked
LOCKED Axis Locked
Axis Status Field Messages
Runtime
Display
Description
