720 Using the RIO Adapter Option
Be careful to select the number of decimal digits such that the expected
maximum values of items in the motion controller can be represented
with the required precision in the PLC.
RIO Adapter Block Transfer Read
32-bit Integer Format Maximum Item Values
Number of Decimal Digits
Maximum Item Value Dec Hex
0
1
2
3
4
5 0
1
2
3
4
5 ±2,147,483,647.0
±214,748,364.7
±21,474,836.47
±2,147,483.647
±214,748.364 7
±21,474.836 47
6
7
8
9
10 6
7
8
9
A ±2,147.483 647
±214.748 364 7
±21.474 836 47
±2.147 483 647
±0.214 748 364 7
11
12
13
14
15 B
C
D
E
F ±0.021 474 836 47
±0.002 147 483 647
±0.000 214 748 364 7
±0.000 021 474 836 47
±0.000 002 147 483 647
