50 Configuring Control Options
3. In the I/O Configuration area, make entries in the following fields:
Field Description
MAC ID (1-99) Enter the Media Access Control (MAC) ID, or
address, of the controller. The value is an integer
from 1 to 99.
Input Bits Select the number of input bits you need from the
pull down list. Available values are:
• 8 (0-7)
• 24 (0-23)
• 40 (0-39)
Input Floats Select the number of input floats you need from
the pull down list. The available values are 0 to 15
(or 14 see note below table).
