Publication GMLC-5.2 - November 1999
168
Working With Modules
Splitting the Diagram Window
To see different areas of the same diagram, you can split the Diagram
Window into two viewing areas, each with its own vertical scroll bar. This
enables you to work on separate modules within the same diagram.
With a diagram displayed, split the Diagram Window by doing the
following:
1. Locate the splitter bar in the top, right-hand corner of the Diagram
Window. The arrow shows the splitter bar above the scroll-bar.
2. Move your cursor to touch the splitter bar. The cursor changes shape
as shown below:
