Publication GMLC-5.2 - November 1999
758 Configuring ControlNet (CNET)
2. In the Tag Window, single-click the right mouse button. A variable
short-cut menu appears.
3. Select New. The CNET Input Bit dialog box appears.
4. Make entries in the following fields:
5. Select OK. The dialog box closes, and the new input appears in the
Tag Window.
Defining Input Floats
If you have enabled input floats (see Defining the I/O Configuration), you
must link each floating point input to a user variable that holds the
floating point value. To do this:
Field Description
Name Type the name of the CNET Input Bit.
Address Type the address, or number, of the bit (from 0
to 39).
Note:
The available address range depends
upon the number of Input Bits you
specified in the CNET page of the
Configure Control Options dialog box.
See Defining the I/O Configuration.
