Publication GMLC-5.2 - November 1999
760 Configuring ControlNet (CNET)
Defining Input Group Bits
After you have selected the number of input bits required for your
application, you can define those bits, either individually or collectively
(or both). To define collections, or groups, of input bits:
1. In the Tag Explorer, select Input Group Bit.
2. In the Tag Window, single-click the right mouse button. A variable
short-cut menu appears.
3. Select New. The CNET Input Group Bit dialog box appears.
4. Make entries to the following fields:
Field Description
Name Type the name of the CNET Input Bit Group.
Address Type the address, or number, of the first bit in
the group.
