Publication GMLC-5.2 - November 1999
Chapter
6
Working with Diagrams
Diagrams are created in the Diagram Window using Commander’s
graphical elements. They are the graphical equivalent of scripted
programs. By creating a diagram you build the instruction set for running
your job.You can create original diagrams or copy and paste parts of
existing diagrams into your new diagram.
Creating a Diagram
Diagrams can be created in two ways:
• Open a new Diagram Widow, add your elements, and save it.
• Open an existing diagram, modify it, and save it with a new name.
Building a New Diagram
Each time you open GML Commander, a new Diagram Window appears,
ready for you to begin developing a new instruction set. You can also use
the New Diagram option on the File menu.
To build a diagram:
1. Select New Diagram from the File option of the menu bar.
