Publication GMLC-5.2 - November 1999
Defining Inputs and Outputs 791
4. Make entries in the following fields:
5. Select OK. The new Output Float appears in the Tag Window.
Field Description
Address Type the address, or number, of the output float.
Note:
The available address range depends
upon the number of Output Floats (from
0 to 14 or 15) you specified in the SLC
page of the Configure Control Options
dialog box. See Defining the I/O
Configuration, above.
List Select the user or axis system variable that is the
source of the floating point value.
Note:
You must first define a User Variable if
it is to appear in the list. See the Online
Help for instructions on defining user
variables.
