Publication GMLC-5.2 - November 1999
Show Program Status 357
Setup Data
If a Setup Data Memory Status type displays a 1—indicating corruption
of the setup parameters—verify that all setup parameter values are correct
by reviewing the data within the Configure Control Options and
Configure Axis Use dialog boxes for each enabled axis. Then, with
Download Axis/Drive Data enabled within the Configure Control Options
dialog box, re-download the application program.
Application Program
If an Application Program Memory Status type displays a 1—indicating
corruption of the application program—re-download the application
program. After re-downloading, be sure to lock the memory using the
front panel keyswitch or the memory unlock jumper to avoid future data
corruption.
Program Size
When you select Program Size from the For menu, the operator interface
displays the size of the current application program (generated from the
GML Commander diagram and downloaded to the motion controller) in
bytes. Controller maximum program sizes are as follows:
The Show Application ID type is most useful when debugging a GML
Commander diagram to identify the current application program in the
motion controller.
!
ATTENTION: After re-downloading, be sure to lock the
memory using the front panel keyswitch or the memory
unlock jumper to avoid future data corruption.
Controller Type: Maximum Program Size:
1394 32 KB
1394 Turbo 64 KB
Compact 32 KB
S Class Integrated/Basic 32 KB
