Rockwell Automation GMLC Reference Manual User Manual
Page 463
Publication GMLC-5.2 - November 1999
426
Display and Operator Interface Blocks
Field Legends
Each field in the runtime display has an associated label, or legend. The
legend may be up to 24 characters long and may contain any legal ASCII
character (see Appendix B for an ASCII reference table) except those
shown in the following table
Axis status is displayed as a text message as shown in the following table.
The status conditions are prioritized from highest to lowest in the order
shown in the table. The higher the status value, the higher its priority (or
severity). In other words, a hardware overtravel fault has higher priority
than a software travel limits fault.
Illegal ASCII Legend Characters
ASCII
Keyboard
Decimal
Hex
Description
LF
CTRL-j
10
0A
Line Feed
ESC
CTRL-[
27
1B
Escape
Axis Status Field Messages
Runtime
Display
Description
AXL FLT
AxisLink Timeout
AXL FLT
AxisLink Fault (axis not found)
AXS OFF
Virtual Axis Not Enabled
DRV FLT
Drive Fault
ERR FLT
Position Error Tolerance Fault
HRD LIM
Hardware Overtravel Fault
SFT LIM
Software Travel Limits Fault
ENC FLT
Encoder Noise or Loss Fault
SRV OFF
Feedback OFF or Virtual Axis Enabled
OUT LIM
Servo Output Limited
