Publication GMLC-5.2 - November 1999
599
If you set the Analog_Test_1_Mode_1394 data parameter to 0 (using a
Control Settings block with Adjust selected), you can also assign this
variable a value (using an Equation block with Configured selected) that
is converted to an equivalent voltage on the A_TEST_1_output_1394.
The voltage range of this output is -10 to +10 Volts.
Axis Count 1394
The Axis_Count_1394 variable reports the number of 1394 Axis
Modules installed.
In the Tag Explorer select General System Variables, then select
Axis_count_1394 in the Tag Window.
System kw 1394
The System_kw_1394 variable reports the kilowatt rating of the 1394
System Module.
In the Tag Explorer select General System Variables, then select
System_kw_1394 in the Tag Window.
System Rated Current 1394
The System_rated_current_1394 variable reports the maximum current
rating of the 1394 system module in Amps.
In the Tag Explorer select General System Variables, then select
System_rated_current_1394 in the Tag Window.
Analog
Test 0 Mode
1394 (D100) Analog Test 0
Axis 1394
(D102) Analog Test
Output 1394
(System Diagnostic Variable)
0 = Generic N/A User-assigned value (converted to equivalent output
voltage to output A_TEST_1)
1 = Velocity 0 – 3 Voltage representation of output A_TEST_1 (1 volt =
1 KRPM)
2 = Torque 0 – 3 Voltage representation of output A_TEST_1 (1 volt =
40% Rated Torque)
