Publication GMLC-5.2 - November 1999
Data Parameters Table 869
Shunt Resistor Power 1394 D133 100 - 22000 Watts 5.0 300
Shunt Resistor Short Time
Constant 1394 D134 0.25 - 2.55 Seconds 2.2 0.25
Shunt Resistor Value 1394 D132 4- 255 Ohms 3.0
4
Shunt STC Weighting Factor
1394 D136 1 - 100% 3.n 5
SLC I/O Update Rate D117 0 = Slow
1 = Medium
2 = Fast 1.0 0 (Slow)
SLC Number of Input Bits D118 0 = 8 (0 - 7)
1 = 24 (0 - 23)
2 = 40 (0 - 39) 1.0 0
SLC Number of Input Floats D119 + Integer < 16 2.0 0
SLC Number of MO:
Floats
Integers
D123
D122 + Integer < 257
+ Integer < 513 3.0
3.0 0
0
SLC Number of MI :
Floats
Integers
D125
D124 + Integer < 257
+ Integer < 513 3.0
3.0 0
0
SLC Number of Output Bits D120 0 = 8 (0 - 7)
1 = 24 (0 - 23)
2 = 40 (0 - 39) 1.0 0
SLC Number of Outputs
Floats D121 + Integer < 16 2.0 0
Software Overtravel Action D40 0 = Kill Drive
1 = Stop Motion
2 = Status Only 1.0 1 (Stop Motion)
Status Display Channel* D37 1 = Serial Port A
2 = Serial Port B 1.0 2 (Serial Port B)
Status Display Refresh Time* D39 Seconds 3.2 0.5 (Seconds)
Data Parameters
Parameter
Parameter
Number
Units
Value
Format
Default
