Defining Flex Inputs and Outputs 445
Defining Flex Inputs and Outputs
You can connect up to eight separate Flex I/O modules to the motion
controller in any order.
To define the inputs and outputs for Flex I/O modules:
1. Select Control Options from the Configure menu. The Configure
Control Options dialog box appears
2. Select the Flex I/O tab to access the Flex I/O page.
3. In the Modules area, make an entry in the following field:
4. Select OK. The Configure Control Options dialog box closes.
Field Description
Modulex 1. Select the module that you want to use.
2. Type a new name for the module.
