Publication GMLC-5.2 - November 1999
Setting the Flex I/O 41
4. Make entries in the following fields:
Note: A protected module is engineered to protect itself against damage
from excess current (emanating from the system module) and
excessive temperature. It shuts itself down if it encounters these
conditions. However, such a module does not shut down and
protect itself from the application of reverse current.
Field Description
Type The type of module you are assigning to this
Flex I/O module. Note: the type of module
selected here determines the fields for input and
output that appear.
Entry Fields The number of entry fields that display on this
page are dependent on the kind of module
selected in the Type field. Each field has a
default value displayed. You may either accept
the default or select an appropriate value from
the pull-down list.
