Rockwell Automation GMLC Reference Manual User Manual
Page 131
Publication GMLC-5.2 - November 1999
94
Configuring Axis Use
Before running any of the diagnostic routines in this dialog box, be sure
that:
•
all external components are properly connected to your system,
•
the GML Commander is operating in ONLINE mode, and
•
the program, including all configured Axis and Drive data, in GML
Commander is the same as the program in the controller.
To configure the Hookups page, make entries in the following fields:
!
ATTENTION: Failure to download can cause
uncontrolled motion when performing controller
diagnostic routines.
