Publication GMLC-5.2 - November 1999
152 Working with Diagrams
3. In the Search area, make entries in the following fields:
4. In the Options area, make entries in the following fields:
Field Description
For Block Type Select to activate the drop-down list of the Find
type field that you use to search for a specific
type of block.
In Block’s
Name Select to activate the Find what field that you
use to search for a block containing all or part
of the name that you type.
In Block’s
Parameters Select to activate the Find what field that you
use to search for a block containing all or part
of the expression value that you type.
For Break Point Select to search for a break point within a
diagram.
Field Description
Match Case Select this to search for text matching exactly
what you type in the Find what field, including
case.
Wrap Select this to make the search automatically
wrap to the beginning of the diagram when it
reaches the end of the diagram.
