Velocity profile – Rockwell Automation GMLC Reference Manual User Manual
Page 108
Publication GMLC-5.2 - November 1999
Defining Position
71
Velocity Profile
Velocity Profile is where you set the motion profiles for Move and Jog.
The available motion profiles are:
•
Trapezoidal - linear acceleration and deceleration
•
S curve - controlled jerk
•
Parabolic - conforms most closely to the torque/speed curve of most
motors
Motion profiles are defined in the following manner,
