Publication GMLC-5.2 - November 1999
Chapter
25
The Expression Builder
The Expression Builder is a specialized calculator for constructing
mathematical expressions in GML Commander. You can open the
Expression Builder within any GML Commander function block for a
field that requires a numeric value or expression.
To access the Expression Builder, place the cursor in the field where you
want to create an expression. Click the right mouse button to display the
menu. (If the menu doesn’t appear, your cursor is not in a field requiring a
numeric value.) Select Build Expression from the menu to access the
Expression Builder dialog box.
Numeric
Keypad
Ta g
E x p lo re r
Tag Window
Operator
Scrolling List
