Publication GMLC-5.2 - November 1999
618 System Functions
Flex I/O Input
Use the Flex_IO_input function to directly specify Flex I/O discrete
inputs in an expression. This function is available only if your motion
controller is running i
CODE version 3.0 or later (as selected in the General
page of the Configure Control Options dialog box).
You define and select Flex I/O discrete inputs in the Tag Explorer (under
Flex I/O Input) and the Tag Window. It is not necessary to use this
function to specify them directly.
Syntax:
Flex_IO_input[module, address]
The Flex_IO_input function is evaluated as 1 (true) if the input is ON and
0 (false) if it is OFF.
Flex I/O Analog Input
Use the Flex_IO_analog_input function to directly specify Flex I/O
analog inputs in an expression. This function is available only if your
motion controller is running i
CODE version 3.0 or later (as selected in the
General page of the Configure Control Options dialog box).
You define and select Flex I/O analog inputs in the Tag Explorer (under
Flex I/O Analog Input) and Tag Window. It is not necessary to use this
function to specify them directly.
Argument Description
Module The Flex I/O module (from 0 to 7) from which output is read.
Address The address of the selected module’s specific output (from 0 to 15) to be
read.
