Defining Inputs and Outputs 759
1. In the Tag Explorer, select Input Float.
2. In the Tag Window, single-click the right mouse button. A variable
short-cut menu appears.
3. Select New. The CNET Input Float dialog box appears.
4. Make entries in the following fields:
5. Select OK. The new Input Float appears in the Tag Window.
Field Description
Address Type the address, or number, of the input float.
Note:
The available address range depends
upon the number of Input Floats (from 0
to 14 or 15) you specified in the CNET
page of the Configure Control Options
dialog box. See Defining the I/O
Configuration.
Tag Window Select a user variable to be linked to the
specified input float.
Note:
You must first define a User Variable if
it is to appear in the list. See the Online
Help for instructions on defining User
Variables.
