Publication GMLC-5.2 - November 1999
Defining Feedback 65
Acceleration and Deceleration Display Format
For a servo axis, type an acceleration and deceleration display format,
using the # character as a placeholder and a decimal point (.) to display
fractional values.
Note: Acceleration and Deceleration Display Format can contain up to
15 digits.
Defining Feedback
The Defining Feedback page is used to make settings that let GML
Commander translate transducer or encoder counts to user-defined
motion measurement units for a physical axis.
To configure the Feedback page, make entries in the following fields:
Transducer Type
Select the type of transducer or encoder that you are using.
Transducer Loss Detection
Click on the Transducer Loss Detection check box to activate it. When in
the active state the controller detects any loss of transducer signal.
