Publication GMLC-5.2 - November 1999
Defining Inputs and Outputs 789
5. Select OK. The name of the new SLC Input Bit Group appears in the
Tag Window.
Defining Output Bits
After you have selected the number of input bits required for your
application, you can define those bits, either individually or collectively
(or both). To define individual input bits:
1. In the Tag Explorer, select Output Bit.
2. In the Tag Window, single-click the right mouse button. A variable
short-cut menu appears.
3. Select New. The SLC Output Bit dialog box appears.
4. Make entries in the following fields:
Field Description
Name Type the name of the SLC Output Bit.
