18
•
Select CHAP as the PPP authentication method.
•
Select ISP domain system (the default ISP domain).
•
Click the Modify button of the ISP domain to perform the configurations shown inFigure 16.
Figure 16 Configure local authentication method for VPN users
•
Select the server type Local as the PPP authentication method.
•
Click Apply to return to the L2TP group configuration page.
•
Type 192.168.0.1/255.255.255.0 as the PPP server IP address/mask.
•
Select Trust from the PPP Server Zone drop-down list. (Select a security zone according to your
network configuration.)
•
Click the Add button of the User Address parameter and then perform the configurations shown
in
.
Figure 17 Add an IP address pool
•
Select domain system.
