23
• Click the icon corresponding to classifier_server on the classifier list, and click Add. Perform
configuration on the page shown in Figure 22 .
Figure 22 Configure rules for class classifier_server
• Select the ACL option, and then select 2000 from the drop-down list.
• Click Apply.
# Create a class named classifier_host, and reference ACL 2001 in the class.
• Select Firewall > QoS > Classifier from the navigation tree, and click Add. Perform
configuration on the page shown in Figure 21 .
• Type classifier_host as the classfier name.
• Click Apply.
• Click the icon corresponding to classifier_host on the classifier list, and click Add. Perform
configuration on the page shown in
Figure 22 .
• Select the ACL option, and then select 2001 from the drop-down list.
• Click Apply.
Step3 Configure traffic behaviors
# Create a behavior named behavior_server, and configure CAR for the behavior.
• Select Firewall > QoS > Behavior from the navigation tree, and click Add. Perform
configuration on the page shown in Figure 23 .
Figure 23 Create a traffic behavior named behavior_server
• Type behavior_server as the behavior name.
• Click Apply.
