Symbol Parameter
Condition
Min.
Typ.
Max.
Units
I
BUSY_TX
Supply current transmit state
P
TX
= 3 dBm
P
TX
= 1 dBm
P
TX
= -3 dBm
P
TX
= -17 dBm
(current consumption is reduced at
V
DD
= 1.8V for each output power level)
14.5
10
9
8
mA
mA
mA
mA
I
RX_ON
Supply current RX_ON state
RX_ON state
12.5
mA
I
RX_ON_P
Supply current RX_ON state
RX_ON state, with register setting
RX_PDT_LEVEL > 0
(1)
12.0
mA
I
PLL_ON
Supply current PLL_ON state
PLL_ON state
5.7
mA
I
TRX_OFF
Supply current TRX_OFF state
TRX_OFF state
0.4
mA
I
SLEEP
Supply current SLEEP state
SLEEP state
0.02
µ
A
Note:
34.8.6 Crystal Parameter Requirements
Symbol Parameter
Condition
Min.
Typ.
Max.
Units
f
0
Crystal frequency
16
MHz
C
L
Load capacitance
8
14
pF
C
0
Static capacitance
7
pF
R
1
Series resistance
100
Ω
35 Typical Characteristics
35.1 Internal Oscillator Speed
t.b.d.
