9.12.33 SHORT_ADDR_1 – Transceiver MAC Short Address Register (High Byte)
Bit 7 6 5 4 3 2 1 0
NA ($161) SHORT_ADDR_17:10 SHORT_ADDR_1
Read/Write RW RW RW RW RW RW RW RW
Initial Value 1 1 1 1 1 1 1 1
This register contains the upper 8 bits of the MAC short address for Frame Filter
address recognition.
• Bit 7:0 – SHORT_ADDR_17:10 - MAC Short Address
These bits contain the bits [15:8] of the MAC short address.
9.12.34 PAN_ID_0 – Transceiver Personal Area Network ID Register (Low Byte)
Bit 7 6 5 4 3 2 1 0
NA ($162) PAN_ID_07:00 PAN_ID_0
Read/Write RW RW RW RW RW RW RW RW
Initial Value 1 1 1 1 1 1 1 1
This register contains the lower 8 bits of the MAC PAN ID for Frame Filter address
recognition.
• Bit 7:0 – PAN_ID_07:00 - MAC Personal Area Network ID
These bits contain the bits [7:0] of the MAC PAN ID.
9.12.35 PAN_ID_1 – Transceiver Personal Area Network ID Register (High Byte)
Bit 7 6 5 4 3 2 1 0
NA ($163) PAN_ID_17:10 PAN_ID_1
Read/Write RW RW RW RW RW RW RW RW
Initial Value 1 1 1 1 1 1 1 1
This register contains the upper 8 bits of the MAC PAN ID for Frame Filter address
recognition.
• Bit 7:0 – PAN_ID_17:10 - MAC Personal Area Network ID
These bits contain the bits [15:8] of the MAC PAN ID.
9.12.36 IEEE_ADDR_0 – Transceiver MAC IEEE Address Register 0
Bit 7 6 5 4 3 2 1 0
NA ($164) IEEE_ADDR_07:00 IEEE_ADDR_0
Read/Write RW RW RW RW RW RW RW RW
Initial Value 0 0 0 0 0 0 0 0
