498
8266A-MCU Wireless-12/09
ATmega128RFA1
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
(0xDE) SCSR Res6 Res5 Res4 Res3 Res2 Res1 Res0 SCBSY 145
(0xDD) SCCR1 Res6 Res5 Res4 Res4 Res3 Res2 Res1 SCENBO 144
(0xDC) SCCR0 SCRES SCMBTS SCEN SCCKSEL SCTSE SCCMP3 SCCMP2 SCCMP1 143
... Reserved
(0xD1) Reserved Res7 Res6 Res5 Res4 Res3 Res2 Res1 Res0
(0xD0) Reserved Res7 Res6 Res5 Res4 Res3 Res2 Res1 Res0
... Reserved
(0xCE) UDR1 UDR17 UDR16 UDR15 UDR14 UDR13 UDR12 UDR11 UDR10 360
(0xCD) UBRR1H Res3 Res2 Res1 Res0 UBRR11 UBRR10 UBRR9 UBRR8 364
(0xCC) UBRR1L UBRR7 UBRR6 UBRR5 UBRR4 UBRR3 UBRR2 UBRR1 UBRR0 365
... Reserved
(0xCA) UCSR1C UMSEL11 UMSEL10 UPM11 UPM10 USBS1 UDORD1 UCPHA1 UCPOL1 376
(0xC9) UCSR1B RXCIE1 TXCIE1 UDRIE1 RXEN1 TXEN1 UCSZ12 RXB81 TXB81 375
(0xC8) UCSR1A RXC1 TXC1 UDRE1 FE1 DOR1 UPE1 U2X1 MPCM1 375
... Reserved
(0xC6) UDR0 UDR07 UDR06 UDR05 UDR04 UDR03 UDR02 UDR01 UDR00 356
(0xC5) UBRR0H Res3 Res2 Res1 Res0 UBRR11 UBRR10 UBRR9 UBRR8 360
(0xC4) UBRR0L UBRR7 UBRR6 UBRR5 UBRR4 UBRR3 UBRR2 UBRR1 UBRR0 360
... Reserved
(0xC2) UCSR0C UMSEL01 UMSEL00 UPM01 UPM00 USBS0 UDORD0 UCPHA0 UCPOL0 374
(0xC1) UCSR0B RXCIE0 TXCIE0 UDRIE0 RXEN0 TXEN0 UCSZ02 RXB80 TXB80 374
(0xC0) UCSR0A RXC0 TXC0 UDRE0 FE0 DOR0 UPE0 U2X0 MPCM0 373
... Reserved
(0xBD) TWAMR TWAM6 TWAM5 TWAM4 TWAM3 TWAM2 TWAM1 TWAM0 Res 406
(0xBC) TWCR TWINT TWEA TWSTA TWSTO TWWC TWEN Res TWIE 402
(0xBB) TWDR TWD7 TWD6 TWD5 TWD4 TWD3 TWD2 TWD1 TWD0 405
(0xBA) TWAR TWA6 TWA5 TWA4 TWA3 TWA2 TWA1 TWA0 TWGCE 405
(0xB9) TWSR TWS7 TWS6 TWS5 TWS4 TWS3 Res TWPS1 TWPS0 403
(0xB8) TWBR TWBR7 TWBR6 TWBR5 TWBR4 TWBR3 TWBR2 TWBR1 TWBR0 401
... Reserved
(0xB6) ASSR EXCLKAMR EXCLK AS2 TCN2UB OCR2AUB OCR2BUB TCR2AUB TCR2BUB 328
... Reserved
(0xB4) OCR2B OCR2B7 OCR2B6 OCR2B5 OCR2B4 OCR2B3 OCR2B2 OCR2B1 OCR2B0 327
(0xB3) OCR2A OCR2A7 OCR2A6 OCR2A5 OCR2A4 OCR2A3 OCR2A2 OCR2A1 OCR2A0 327
(0xB2) TCNT2 TCNT27 TCNT26 TCNT25 TCNT24 TCNT23 TCNT22 TCNT21 TCNT20 327
(0xB1) TCCR2B FOC2A FOC2B Res1 Res0 WGM22 CS22 CS21 CS20 326
(0xB0) TCCR2A COM2A1 COM2A0 COM2B1 COM2B0 Res1 Res0 WGM21 WGM20 325
... Reserved
(0xAD) OCR4CH OCR4CH7 OCR4CH6 OCR4CH5 OCR4CH4 OCR4CH3 OCR4CH2 OCR4CH1 OCR4CH0 291
(0xAC) OCR4CL OCR4CL7 OCR4CL6 OCR4CL5 OCR4CL4 OCR4CL3 OCR4CL2 OCR4CL1 OCR4CL0 292
(0xAB) OCR4BH OCR4BH7 OCR4BH6 OCR4BH5 OCR4BH4 OCR4BH3 OCR4BH2 OCR4BH1 OCR4BH0 291
(0xAA) OCR4BL OCR4BL7 OCR4BL6 OCR4BL5 OCR4BL4 OCR4BL3 OCR4BL2 OCR4BL1 OCR4BL0 291
(0xA9) OCR4AH OCR4AH7 OCR4AH6 OCR4AH5 OCR4AH4 OCR4AH3 OCR4AH2 OCR4AH1 OCR4AH0 290
(0xA8) OCR4AL OCR4AL7 OCR4AL6 OCR4AL5 OCR4AL4 OCR4AL3 OCR4AL2 OCR4AL1 OCR4AL0 290
(0xA7) ICR4H ICR4H7 ICR4H6 ICR4H5 ICR4H4 ICR4H3 ICR4H2 ICR4H1 ICR4H0 292
(0xA6) ICR4L ICR4L7 ICR4L6 ICR4L5 ICR4L4 ICR4L3 ICR4L2 ICR4L1 ICR4L0 292
(0xA5) TCNT4H TCNT4H7 TCNT4H6 TCNT4H5 TCNT4H4 TCNT4H3 TCNT4H2 TCNT4H1 TCNT4H0 289
(0xA4) TCNT4L TCNT4L7 TCNT4L6 TCNT4L5 TCNT4L4 TCNT4L3 TCNT4L2 TCNT4L1 TCNT4L0 289
... Reserved
(0xA2) TCCR4C FOC4A FOC4B FOC4C Res4 Res3 Res2 Res1 Res0 288
(0xA1) TCCR4B ICNC4 ICES4 Res WGM43 WGM42 CS42 CS41 CS40 287
(0xA0) TCCR4A COM4A1 COM4A0 COM4B1 COM4B0 COM4C1 COM4C0 WGM41 WGM40 285
... Reserved
(0x9D) OCR3CH OCR3CH7 OCR3CH6 OCR3CH5 OCR3CH4 OCR3CH3 OCR3CH2 OCR3CH1 OCR3CH0 282
(0x9C) OCR3CL OCR3CL7 OCR3CL6 OCR3CL5 OCR3CL4 OCR3CL3 OCR3CL2 OCR3CL1 OCR3CL0 283
(0x9B) OCR3BH OCR3BH7 OCR3BH6 OCR3BH5 OCR3BH4 OCR3BH3 OCR3BH2 OCR3BH1 OCR3BH0 282
(0x9A) OCR3BL OCR3BL7 OCR3BL6 OCR3BL5 OCR3BL4 OCR3BL3 OCR3BL2 OCR3BL1 OCR3BL0 282
(0x99) OCR3AH OCR3AH7 OCR3AH6 OCR3AH5 OCR3AH4 OCR3AH3 OCR3AH2 OCR3AH1 OCR3AH0 281
(0x98) OCR3AL OCR3AL7 OCR3AL6 OCR3AL5 OCR3AL4 OCR3AL3 OCR3AL2 OCR3AL1 OCR3AL0 281
(0x97) ICR3H ICR3H7 ICR3H6 ICR3H5 ICR3H4 ICR3H3 ICR3H2 ICR3H1 ICR3H0 283
(0x96) ICR3L ICR3L7 ICR3L6 ICR3L5 ICR3L4 ICR3L3 ICR3L2 ICR3L1 ICR3L0 283
(0x95) TCNT3H TCNT3H7 TCNT3H6 TCNT3H5 TCNT3H4 TCNT3H3 TCNT3H2 TCNT3H1 TCNT3H0 280
(0x94) TCNT3L TCNT3L7 TCNT3L6 TCNT3L5 TCNT3L4 TCNT3L3 TCNT3L2 TCNT3L1 TCNT3L0 280
... Reserved
