142
8266A-MCU Wireless-12/09
ATmega128RFA1
10.11.18 SCOCR2HL – Symbol Counter Output Compare Register 2 HL-Byte
Bit 7 6 5 4 3 2 1 0
NA ($F3) SCOCR2HL7:0 SCOCR2HL
Read/Write RW RW RW RW RW RW RW RW
Initial Value 0 0 0 0 0 0 0 0
This register contains the second most significant byte of the 32 bit compare value for
the second compare unit
• Bit 7:0 – SCOCR2HL7:0 - Symbol Counter Output Compare Register 2 HL-Byte
10.11.19 SCOCR2LH – Symbol Counter Output Compare Register 2 LH-Byte
Bit 7 6 5 4 3 2 1 0
NA ($F2) SCOCR2LH7:0 SCOCR2LH
Read/Write RW RW RW RW RW RW RW RW
Initial Value 0 0 0 0 0 0 0 0
This register contains the second least significant byte of the 32 bit compare value for
the second compare unit
• Bit 7:0 – SCOCR2LH7:0 - Symbol Counter Output Compare Register 2 LH-Byte
10.11.20 SCOCR2LL – Symbol Counter Output Compare Register 2 LL-Byte
Bit 7 6 5 4 3 2 1 0
NA ($F1) SCOCR2LL7:0 SCOCR2LL
Read/Write RW RW RW RW RW RW RW RW
Initial Value 0 0 0 0 0 0 0 0
This register contains the least significant byte of the 32 bit compare value for the
second compare unit
• Bit 7:0 – SCOCR2LL7:0 - Symbol Counter Output Compare Register 2 LL-Byte
10.11.21 SCOCR3HH – Symbol Counter Output Compare Register 3 HH-Byte
Bit 7 6 5 4 3 2 1 0
NA ($F0) SCOCR3HH7:0 SCOCR3HH
Read/Write RW RW RW RW RW RW RW RW
Initial Value 0 0 0 0 0 0 0 0
This register contains the most significant byte of the 32 bit compare value for the third
compare unit
• Bit 7:0 – SCOCR3HH7:0 - Symbol Counter Output Compare Register 3 HH-Byte
