ATmega128RFA1
MUX5:0
Single Ended
Input
Positive Differential
Input
Negative Differential
Input Gain
000110 ADC6
000111 ADC7
001000 ADC0 ADC0 10x
001001 ADC1 ADC0 10x
001010 ADC0 ADC0 200x
001011 ADC1 ADC0 200x
001100 ADC2 ADC2 10x
001101 ADC3 ADC2 10x
001110 ADC2 ADC2 200x
001111
N/A
ADC3 ADC2 200x
010000 ADC0 ADC1 1x
010001 ADC1 ADC1 1x
010010 ADC2 ADC1 1x
010011 ADC3 ADC1 1x
010100 ADC4 ADC1 1x
010101 ADC5 ADC1 1x
010110 ADC6 ADC1 1x
010111
N/A
ADC7 ADC1 1x
011000 ADC0 ADC2 1x
011001 ADC1 ADC2 1x
011010 ADC2 ADC2 1x
011011 ADC3 ADC2 1x
011100 ADC4 ADC2 1x
011101
N/A
ADC5 ADC2 1x
011110 1.2V (V
BG
)
011111 0V (AVSS)
N/A
100000 Reserved
100001 Reserved
100010 Reserved
100011 Reserved
100100 Reserved
100101 Reserved
100110 Reserved
100111 Reserved
N/A
101000 Reserved
101001 Temperature Sensor
101010 Reserved
101011 Reserved
101100 Reserved
101101 Reserved
101110
N/A
Reserved
