17.9.6 OCR0B – Timer/Counter0 Output Compare Register B
Bit 7 6 5 4
$28 ($48) OCR0B_7 OCR0B_6 OCR0B_5 OCR0B_4 OCR0B
Read/Write RW RW RW RW
Initial Value 0 0 0 0
Bit 3 2 1 0
$28 ($48) OCR0B_3 OCR0B_2 OCR0B_1 OCR0B_0 OCR0B
Read/Write RW RW RW RW
Initial Value 0 0 0 0
The Output Compare Register B contains an 8-bit value that is continuously compared
with the counter value (TCNT0). A match can be used to generate an Output Compare
interrupt, or to generate a waveform output on the OC0B pin.
• Bit 7:0 – OCR0B_7:0 - Output Compare Register
17.9.7 TIMSK0 – Timer/Counter0 Interrupt Mask Register
Bit 7 6 5 4 3 2 1 0
NA ($6E) Res4 Res3 Res2 Res1 Res0 OCIE0B OCIE0A TOIE0 TIMSK0
Read/Write R R R R R RW RW RW
Initial Value 0 0 0 0 0 0 0 0
• Bit 7:3 – Res4:0 - Reserved
This bit is reserved for future use. A read access always will return zero. A write access
does not modify the content.
• Bit 2 – OCIE0B - Timer/Counter0 Output Compare Match B Interrupt Enable
When the OCIE0B bit is written to one, and the I-bit in the Status Register is set, the
Timer/Counter0 Compare Match B interrupt is enabled. The corresponding interrupt is
executed if a Compare Match in Timer/Counter0 occurs, i.e., when the OCF0B bit is set
in the Timer/Counter0 Interrupt Flag Register TIFR0.
• Bit 1 – OCIE0A - Timer/Counter0 Output Compare Match A Interrupt Enable
When the OCIE0A bit is written to one, and the I-bit in the Status Register is set, the
Timer/Counter0 Compare Match A interrupt is enabled. The corresponding interrupt is
executed if a Compare Match in Timer/Counter0 occurs, i.e., when the OCF0A bit is set
in the Timer/Counter0 Interrupt Flag Register TIFR0.
• Bit 0 – TOIE0 - Timer/Counter0 Overflow Interrupt Enable
When the TOIE0 bit is written to one, and the I-bit in the Status Register is set, the
Timer/Counter0 Overflow interrupt is enabled. The corresponding interrupt is executed
if an overflow in Timer/Counter0 occurs i.e., when the TOV0 bit is set in the
Timer/Counter0 Interrupt Flag Register TIFR0.
