13.5 Register Description

13.5.1 MCUSR – MCU Status Register

Bit

7

6

5

4

3

2

1

0

$34 ($54)

Res2

Res1

Res0

JTRF

WDRF

BORF

EXTRF

PORF

MCUSR

Read/Write

R

R

R

RW

R/W

R/W

R/W

R/W

Initial Value

0

0

0

0

0

0

0

0

The MCU Status Register provides information on which reset source caused an MCU
reset. To make use of the Reset Flags to identify a reset condition, the user should read
and then Reset the MCUSR as early as possible in the program. If the register is
cleared before another reset occurs, the source of the reset can be found by examining
the Reset Flags. Note, after power on the bit EXTRF has to be ignored.

Bit 7:5 – Res2:0 - Reserved

Bit 4 – JTRF - JTAG Reset Flag

This bit is set if a reset is being caused by a logic one in the JTAG Reset Register
selected by the JTAG instruction AVR_RESET. This bit is reset by a Power-on Reset,
or by writing a logic zero to the flag.

Bit 3 – WDRF - Watchdog Reset Flag

This bit is set if a Watchdog Reset occurs. The bit is reset by a Power-on Reset, or by
writing a logic zero to the flag.

Bit 2 – BORF - Brown-out Reset Flag

This bit is set if a Brown-out Reset occurs. The bit is reset by a Power-on Reset, or by
writing a logic zero to the flag.

Bit 1 – EXTRF - External Reset Flag

This bit is set if an External Reset occurs. The bit is reset by a Power-on Reset, or by
writing a logic zero to the flag.

Bit 0 – PORF - Power-on Reset Flag

This bit is set if a Power-on Reset occurs. The bit is reset only by writing a logic zero to
the flag.

13.5.2 WDTCSR – Watchdog Timer Control Register

Bit

7

6

5

4

3

2

1

0

NA ($60)

WDIF

WDIE

WDP3

WDCE

WDE

WDP2

WDP1

WDP0

WDTCSR

Read/Write

RW

RW

RW

RW

RW

RW

RW

RW

Initial Value

0

0

0

0

0

0

0

0

Bit 7 – WDIF - Watchdog Timeout Interrupt Flag

This bit is set when a time-out occurs in the Watchdog Timer and the Watchdog Timer
is configured for interrupt. WDIF is cleared by hardware when executing the
corresponding interrupt handling vector. Alternatively, WDIF is cleared by writing a logic
one to the flag. When the I-bit in SREG and WDIE are set, the Watchdog Time-out
Interrupt is executed.
