Allied Telesis AT-S60 - Manual (Page 801)

AT-S60 Management Software User’s Guide
Section VI: Web Browser Management 801
Configuring RADIUS
To configure RADIUS, perform the following procedure:
1. From the Home Page, select Configuration.
The Configuration System Page is displayed with the General Tab
selected by default, as shown in Figure 192 on page 584.
2. Select the Server-based Authentication Tab.
The Server-based Authentication Tab is displayed as shown in
Figure 295 on page 797.
3. Click the check circle next to RADIUS Configuration and click
Configure.
The RADIUS Client Configuration Page is shown in Figure 297.
Figure 297 RADIUS Client Configuration Page
4. Configure the following parameters as needed:
Global Encryption Key
If all of the TACACS+ servers have the same encryption secret, you
can enter the key here. If the servers have different keys, you must
specify each key when you specify a server’s IP address.
Global Server Timeout
This parameter specifies the maximum amount of time the switch
waits for a response from a TACACS+ server before assuming the
server cannot respond. If the timeout expires and the server has
not responded, the switch queries the next TACACS+ server in the
list. If there are no more servers, then the switch defaults to the
standard Manager and Operator accounts. The default is 30
seconds. The range is from 1 to 30 seconds.
