Chapter 6: Port Parameters
Section I: Basic Features 102
Displaying Port Status
This section provides a procedure to display the status of a port. To
display port statistics, see Displaying Port Statistics on page 112.
To display the status of the ports on the switch, perform the following
procedure:
1. From the Main Menu, type 1 to select Port Menu.
The Port Menu is shown in Figure 26.
Figure 26 Port Menu
2. From the Port Menu, type 2 to select Port Status.
The Port Status Menu is shown in Figure 27.
Figure 27 Port Status Menu
Allied Telesyn AT-8400 Series - AT-S60 V2.1.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2004
Port Menu
1 - Port Configuration
2 - Port Status
3 - Port Statistics
4 - Port Trunking
5 - Port Mirroring
R - Return to Previous Menu
Enter your selection?
Allied Telesyn AT-8400 Series - AT-S60 V2.1.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2004
Port Status
Port Media Status Link Neg MDI/X Speed Duplex PVID Flow Ctl STP Pri
-----------------------------------------------------------------------------------
1.1
FIBER Enabled Up Auto MDI 0010 Half 0001 Disabled Fwd No
1.2 FIBER Enabled Up Auto MDI 0100 Full 0001 Disabled Fwd No
1.3 FIBER Enabled Up Auto MDI 0100 Full 0001 Disabled Fwd No
1.4 FIBER Enabled Up Auto MDI 0100 Full 0001 Disabled Fwd No
2.1 GBIC Enabled Up Manual MDI 1000 Full 0001 Auto Fwd No
3.1 TP Enabled Up Manual MDIX 1000 Full 0001 Auto Fwd No
9.1 FIBER Enabled Up Auto MDI 0100 Full 0001 Disabled Fwd No
9.2 FIBER Enabled Up Auto MDI 0010 Half 0001 Disabled Fwd No
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
