Chapter 28: 802.1x Port-based Access Control
Section V: Security Features 572
The Display Port Access Status menu is shown in Figure 187.
Figure 187 Display Port Access Status Menu
4. The Display Port Access Status menu has the following parameters:
Port - lists the port number of the line card.
PortRole - lists the port access role configured for the port. Values
can be None, Authenticator, or Supplicant.
State - lists the status of the port. The status field is dependent on
whether a port is configured as an authenticator or a supplicant.
When you configure a port with an Authenticator Role, the Status
field can have the following values:
Aborting
Authenticated
Authenticating
Connecting
Disconnected
Force_Auth
Force_Unauth
Held
Initialize
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
Production Switch 142
User: Manager 00:14:33 22-Mar-2004
Display Port Access Status
Port PortRole State Additional Info
---------------------------------------------------------------
6.1 None ------ -------------------
6.2 Authenticator Connecting -------------------
6.3 Authenticator Authenticated 00:a0:d2:18:1a:c8
6.4 Authenticator Connecting -------------------
6.5 None ------ -------------------
6.6 None ------ -------------------
6.7 None ------ -------------------
6.8 Supplicant ------ --------------------
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
