Chapter 15: STP and RSTP
Section II: Advanced Features 252
Configuring
RSTP Port
Parameters
To adjust a port’s RSTP parameters, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Menu.
The Spanning Tree Menu is shown in Figure 74 on page 240.
2. From the Spanning Tree Menu, type 4 to select RSTP Configuration.
The RSTP Menu is shown in Figure 79 on page 249.
3. From the RSTP Configuration menu, type P to select RSTP Port
Parameters.
The RSTP Port Parameters Menu is shown in Figure 80.
Figure 80 RSTP Port Parameters Menu
4. Type 1 to select Configure RSTP Port Settings.
The following prompt is displayed:
Enter port-list:
5. Enter the port to configure.
For instructions on how to specify port numbers, refer to
Specifying Ports on page 34.
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2004
RSTP Port Parameters
1 - Configure RSTP Port Settings
2 - Display RSTP Port Configuration
3 - Display RSTP Port State
R - Return to Previous Menu
Enter your selection?
