Allied Telesis AT-S60 - Manual (Page 111)

AT-S60 Management Software User’s Guide
Section I: Basic Features 111
Note
MDI/X applies only to copper ports, not fiber ports.
B - Media Selection
Use this parameter to select the media type on an AT-8413 line
card. This parameter is only available when the Negotiation
parameter is set to manual.
Choose from the following settings:
❑ Type GBIC (for GBIC port) to indicate only the GBIC port is available
for connectivity.
❑ Type TP (for twisted pair) to indicate only the twisted pair port is
available for connectivity.
D - Set Default Port Configuration
Use this selection to reset the port parameters to their default
values. The port parameter defaults are illustrated in Figure 28 on
page 106.
5. After setting the port parameters, type R until you return to the Main
Menu. Then type S to select Save Configuration Changes.
Configuration changes are immediately activated on a port.
