Chapter 20: GARP VLAN Registration Protocol
Section IV: VLANs 464
GIP Connected
Ports Ring
Option 3 - Display GIP Connected Ports Ring in the Other GARP Port
Parameters displays the GIP Connected Ports Ring Menu as shown in
Figure 148.
Figure 148 GIP Connected Ports Ring Menu
The information in the menu is defined in Table 16. This information is
for viewing purposes only.
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
Production Switch 4
User: Manager 00:14:33 24-May-2004
GIP Connected Ports Ring
GARP Application: GVRP
GIP Context ID: 0, STP ID: 0
-------------------------------------------------------------
1.2 -> 1.8 -> 4.4
U - Update Display
R - Return to Previous Menu
Enter your selection?
Table 16 GIP Connected Ports Ring Parameters
Parameter Meaning
GARP Application Identifies the GARP application, that is,
“GVRP.”
GIP Context Index ID A number assigned to the instance for the
GIP context.
STP ID Present if the GARP application is GVRP;
identifies the STP that has these ports
connected in the GIP connected ring.
Connected Ring Ring of connected ports. Only ports
presently in the STP Forwarding state are
eligible for membership to the GIP
connected ring. If no ports exist in the GIP
connected ring, “No ports are connected” is
displayed. If the GARP application has no
ports, “No ports have been assigned” is
displayed.
