Allied Telesis AT-S60 - Manual (Page 770)

Chapter 42: GARP VLAN Registration Protocol
Section VI: Web Browser Management 770
Modifying the GVRP Port Configuration
To modify the GVRP port configuration:
1. From the Home Page, select Configuration.
The Configuration System Page is displayed with the General Tab
selected by default, as shown in Figure 192 on page 584.
2. From the Configuration menu, select the Layer 2 option.
The Layer 2 Page is displayed with the MAC Address Tab selected
by default, as shown in Figure 212 on page 634.
3. Select the GVRP Tab.
The GVRP Tab is shown in Figure 281 on page 767.
4. Select a port.
5. Click Modify.
The GVRP Port Configuration Page is shown in Figure 282.
Figure 282 GVRP Port Configuration Page
6. Change the port mode if desired.
7. Click Apply.
