Chapter 5: SNMPv1 and SNMPv2c Configuration
Section I: Basic Features 100
Displaying an SNMPv1 and SNMPv2c Community
Use the following procedure to display the attributes of an SNMPv1 and
SNMPv2c communities.
1. From the Main Menu, type 5 to select System Menu.
The System Menu is shown in Figure 5 on page 51.
2. From the System Menu, type 1 to select Configure System.
The Configure System Menu is shown in Figure 11 on page 59.
3. From the Configure System Menu, type 1 to select Configure System
Software.
The Configure System Software Menu is shown in Figure 12 on
page 60.
4. From the Configure System Software Menu, type 8 to select
Configure SNMP.
The Configure SNMP Menu is shown in Figure 22 on page 87.
5. To display the attributes of an SNMPv1 and SNMPv2c community,
type 4 to select Display SNMPv1 & SNMPv2c Community.
The Display SNMPv1 & SNMPv2c Community Menu is shown in
Figure 25.
Figure 25 Display SNMPv1 & SNMPv2c Community Menu
Note
Within an SNMP community, Trap Receiver IP addresses are
automatically added to an internal Manager IP address list. This
information is not displayed.
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2004
Display SNMPv1 & SNMPv2c Community
Community Name Access Mode Status OpenAcc Manager IP Addr Trap Receiver IP
====================================================================================
Private125 Read|Write Enabled No 147.41.11.30 147.45.16.70
147.45.16.80 147.45.16.80
PublicATI78 Read Only Enabled No 147.41.11.12 147.42.22.22
147.44.16.86 147.45.16.86
147.45.16.88 147.45.16.88
147.45.16.90 147.45.16.90
HighSchool2 Read|Write Enabled No 147.45.10.80 147.45.10.80
U - Update Display
R - Return to Previous Menu
Enter your selection?
