Chapter 40: SNMPv3 Protocol
Section VI: Web Browser Management 724
NonVolatile
Select this storage type if you want the ability to save an entry in
the Notify Table to the configuration file. After making changes to
a Notify Table entry with a NonVolatile storage type, Save
Changes appears on the General Tab.
Note
The Row Status parameter is a read-only field in the Web interface.
The Active value indicates the SNMPv3 Notify Table entry takes
effect immediately.
9. Click Apply to update the SNMPv3 Notify Table.
10. To save your changes, return to the General Tab and click Save
Changes.
Deleting a
Notify Table
Entry
To delete an entry in the SNMPv3 Notify Table, perform the following
procedure.
1. From the Home Page, select Configuration.
The Configuration System Page is displayed with the General Tab
selected by default, as shown in Figure 192 on page 584.
2. Select the SNMP Tab.
The SNMP Tab is shown in Figure 195 on page 596.
3. In the SNMPv3 section of the page, click the circle next to Configure
Notify Table. Then click Configure at the bottom of the page.
The SNMPv3 Notify Table Page is shown in Figure 255 on page
722.
4. Click the circle next to the Notify Table entry that you want to delete.
Then click Remove.
A warning message is displayed. Click OK to remove the SNMPv3
Notify Table entry.
5. To save your changes, return to the General Tab and click Save
Changes.
Modifying a
Notify Table
Entry
To modify an entry in the SNMPv3 Notify Table, perform the following
procedure.
1. From the Home Page, select Configuration.
The Configuration System Page is displayed with the General Tab
selected by default, as shown in Figure 192 on page 584.
2. Select the SNMP Tab.
The SNMP Tab is shown in Figure 195 on page 596.
