Chapter 27: TACACS+ and RADIUS Protocols
Section V: Security Features 548
the server cannot respond. If the timeout expires and the server
hasn’t responded, the switch queries the next RADIUS server in
the list. If there aren’t any more servers in the list, then the switch
defaults to the standard Manager and Operator accounts. The
default is 30 seconds. The range is 1 to 60 seconds.
3 - RADIUS Server 1 Configuration
4 - RADIUS Server 2 Configuration
5 - RADIUS Server 3 Configuration
Use these parameters to specify the IP addresses of up to three
network servers containing the RADIUS server software. Selecting
one of the above options displays the RADIUS Server
Configuration Menu as shown in Figure 176.
Figure 176 RADIUS Server Configuration Menu
The options are described below:
1 - Server IP Address
Use this option to specify the IP address of the RADIUS server.
2 - Server Authentication UDP Port
Use this option to specify the UDP port of the RADIUS
protocol. This is an internal port number used by the TCP/IP
stack to determine which application an incoming message is
sent to.
3 - Server Encryption Key
Use this option to specify the encryption key for the RADIUS
server. This is an alphanumeric value with a maximum length
of 24 characters.
5. After configuring the parameters, type R until you return to the Main
Menu. Then type S to select Save Configuration Changes.
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
Engineering Switch 142
User: Manager 00:14:39 01-Jan-2004
RADIUS Server 1 Configuration
1 - Server IP Address ................. 0.0.0.0
2 - Server Authentication UDP Port .... 1812
3 - Server Encryption Key ........
R - Return to Previous Menu
Enter your selection?
