Chapter 11: File Downloads and Uploads
Section II: Advanced Features 188
Uploading an
Image File
Using Xmodem
or TFTP
The following procedures describe how to upload an .img file type
(image file) only. To upload other file types, see Uploading a File Using
Xmodem or TFTP on page 194. See Table 5 on page 168 for a list of file
types.
To upload a file from a switch onto your management station, perform
the following procedure:
Note
Allied Telesyn does not recommend that you upload an AT-S60
software image onto a management workstation for the purpose of
downloading it onto another switch. Obtain new AT-S60 software
images for downloading onto a switch from the Allied Telesyn web
site.
1. Start a local management session on the switch where you intend to
upload the management software image or configuration file.
2. From the Main Menu, type 4 to select Administration Menu.
3. From the Administration Menu, type D to select Downloads &
Uploads.
The Downloads & Uploads menu is shown in Figure 54.
Figure 54 Downloads & Uploads Menu
Note
Menu options 1 and 3 are described in Downloading an Image File
Using Xmodem or TFTP on page 173. Option 4 is described in
Uploading a File Using Xmodem or TFTP on page 194.
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
High School Switch 142
User: Manager 00:14:33 01-Jan-2004
Downloads & Uploads
1 - Download Application Image/BootLoader
2 - Upload Application Image/BootLoader
3 - Download a File
4 - Upload a File
R - Return to Previous Menu
Enter your selection?
