AT-S60 Management Software User’s Guide
Section I: Basic Features 109
Disabled - Indicates that no flow control occurs on the port.
Enabled - Indicates that flow control occurs on the port.
7 - Negotiation
You use this selection to configure a port for Auto-Negotiation or
to manually set a port’s speed and duplex mode.
Press 7 to toggle between the following settings:
❑ Auto - Select Auto (for Auto-Negotiation) to set both speed and
duplex mode for the port automatically.
Note
For the AT-8412/SC FX and AT-8412/MT FX line cards, the default
setting of the Negotiation parameter is Manual. The default setting
for ports on all the other line cards is Auto.
❑ Manual - Select Manual to set the speed and duplex for the port.
If you select Manual, four additional selections are displayed in the
Port Configuration menu:
8 - Speed ................. 0100
9 - Duplex ................ Full
A - MDI/MDIX Crossover .... MDIX
B - Media Selection ....... GBIC
You use the selections listed above to configure the port’s speed,
duplex mode, MDI/MDI/X, and media selection settings.
8 - Speed
You use this selection to configure the port speed. See Table 1 for
port speed settings for each line card. Choose from the following
options:
❑ 0010 - Indicates 10 Mbps.
❑ 0100 - Indicates 100 Mbps.
❑ 1000 - Indicates 1000 Mbps.
Table 1 Line Card Port-Speed Settings
Line Card Port Speed
AT-8411 TX 10/100 Mbps
AT-8412/SC FX
AT-8412/MT FX 100 Mbps
